The classification or “family tree” of electric machines today
ABSTRACT
At this time of great disruption, many engineers will take time to reflect on their work and studies. As it has happened in the past, improved understanding and new methods have emerged from periods of difficulty, and this will surely happen again. This engineering webinar series sponsored by JMAG and Powersys is intended as a contribution to this process. Prof. Miller begins by reviewing the entire family of electric machines, uncovering the theoretical and manufacturing reasons why machines are built and used as they are today. He draws particular attention to the unity of the family of AC drives, which includes the asynchronous induction motor and the brushless PM motor as well as the AC synchronous machines.
The profound influence of electronic control is made clear, not only in relation to its history but also for the present and the future. Equally the impact of modern permanent-magnet materials is shown in detail, and the question of scarcity is discussed. DC machines, universal motors, and the important classes of reluctance machines are shown to be full members of today's family of electric machines with important roles. We hope the webinar will appeal to a wide audience. For anyone new to the industry, it can be used as an introduction. Students may find it helpful in sorting out the confusing array of different machine types. Specialists (including the expert users of sophisticated software tools) may like to take a break and enjoy a wider view. And experienced designers and users may compare their own reflections on the electric machine industry through this unifying review.
Program
These automatic captions are generated by machine learning algorithms, so the quality of the captions may vary.
In order to view the download data or video, you need the ID and password.
JMAG Software Authorized User ID
This ID is issued based on the JMAG license agreement. At the time of contract, we will guide you to the license administrator by e-mail.
It is also available for those who are in the free trial period.
*A user ID and password which is described in the e-mail we sent you with JMAG license file are required.
The 73rd seminar serves as the final session of the five-seminar series on synchronous machine analysis (Vol. 69–73). Focusing on “inverter-fed machines,” which are indispensable in modern design practice, it outlines a practical approach to analysis aligned with real-world operation, moving beyond classical analysis based on commercial power-driven systems. The seminar covers topics such as changes in the voltage waveform due to PWM control and the concept of space vectors.
In particular, it is crucial to examine how magnetic saturation and mutual saturation affect various parameters by combining finite element analysis (FEM) with phasor diagrams in order to ensure consistency with actual device behavior. This process offers perspectives directly relevant to design and analysis, including the use of Ld and Lq as well as the maximization of torque under inverter voltage constraints.
This seminar offers essential insights into how the theory covered throughout the series can be applied to real-world drive systems.
In this video Prof. Miller explains the close relationship between the circuit theory, the control theory, and the field theory of electric machines. After a brief review of the nature of performance calculations, we see how the concept of the space-vector unifies the physical principles and the control methods for DC and AC machines, and goes beyond the scope of classical teaching to include the power-electronic switching inverter. The space-vector concept is explained in detail alongside Park’s transform, which is used to deal with saturation in the important IPM motor, using the finite-element method in an extremely efficient way. The conclusion is that a set of modern software tools redefines (and greatly extends) the classical conc…
In this third seminar, we will be covering discussion regarding numbers of poles.This involves discussing the merits of a large number of slots per pole, the difference in magnetic circuits when changing the number of poles, and the relationship between the number of poles and inductance. All this and more is explained with a focus on the number of poles as the central theme.The number of poles provides the opportunity to re-examine electric machines from a new perspective. We look forward to your participation.
Noisy Lumpy Growling Effects in the Induction Motor
In this fourth seminar, we will be covering discussion regarding the parasitic torque and noise of induction motors.Factors that cause torque are shown through the analysis of the spatial harmonics of windings, and both the parasitic torque and noise of induction motors are explained based on the relationship between noise and torque irregularities. While a total comprehension of all the concepts covered in this seminar might be something of a challenge, referring to the Green Book should help forge a deeper understanding.
The Flux-weakening Phasor Diagram of the Brushless Surface-Magnet PM Motor
In this fifth seminar, we will be covering discussion regarding the phasor diagrams of SPM motors.This involves creating phasor diagrams from scratch, and using phasor diagrams in particular to describe the principle of weakening magnetic flux in the high speed regions of PM motors.Also referring to the Green Book should aid in a deeper understanding of these concepts.
Analysis of a Brushless Surface-Magnet PM Motor -Winding layout-
This sixth seminar begins discussion on analyzing the features of surface permanent magnet motors, introducing rules for drawing coils and methods for creating winding diagrams and estimating motor performance with winding designs.
Analysis of a Brushless Surface-Magnet PM Motor -Magnetic and Electrical calculations-
This seventh seminar sees the second discussion regarding surface permanent magnet motors, with magnetic and electrical calculations executed in accordance with classical theories.This involves calculating the time harmonic components of induced voltage, followed by the calculation of magnetizing inductance before a finer disassembly of the other inductances.
Preliminary Design of a 3-phase Induction Motor (Part 1: Stator)
This seventh seminar sees the second discussion regarding surface permanent magnet motors, with magnetic and electrical calculations executed in accordance with classical theories.This involves calculating the time harmonic components of induced voltage, followed by the calculation of magnetizing inductance before a finer disassembly of the other inductances.
Preliminary Design of a 3-phase Induction Motor (Part 2 : Stator winding design)
This ninth seminar consists of the second part of our continuing focus on induction motor design.In the first part we introduced the outer design of the stator, whereas this time we will be turning our attention to designing the stator winding.For this we will be using short pitch winding. This seminar will explain both why this was chosen, as well as information on the distribution factor.We hope that all those joining us will be looking forward to our next seminar, where the third part of this ongoing series will be talking a look at rotor concept design.
Preliminary Design of a 3-phase Induction Motor (Part 3 : Rotor)
This tenth seminar is Part 3 of designing an induction motor.The previous two seminars showed the process of determining the size of the motor and subsequently developing the stator design.This time the focus will be on rotor design.The workflow involves first determining the air-gap length, then the number of rotor slots and finally, the slot geometry.Guidelines for determining the design parameters are shown with the explanations.
Preliminary Design of a 3-phase Induction Motor (Part 4 : Equivalent circuit)
This eleventh seminar is Part 4 of designing an induction motor.In this seminar, the induction motor is modeled using an equivalent circuit, a practical tool for checking the basic characteristics of the design. Starting with an introduction of the equivalent circuit of the transformer, it explains the use of an equivalent circuit in the induction motor. We hope the seminar will be useful in understanding how to use an equivalent circuit in modeling the induction motor that rotates asynchronously with the rotation of the magnetic field.The seminar shows up to the stage where actual calculation of primary and secondary resistance are performed.
Preliminary Design of a 3-phase Induction Motor (Part 5 : Equivalent circuit reactances — Magnetizing reactance)
This twelfth seminar is Part 5 of designing an induction motor.In this seminar, we will try to calculate the magnetizing reactance in the equivalent circuit of the induction motor.The magnetizing reactance is one of the most important concepts in the induction motor theory.The seminar focuses on explaining magnetizing reactance by using both the classical theory and the finite-element method.
Preliminary Design of a 3-phase Induction Motor (Part 6 : Equivalent circuit; Stator slot-leakage reactance)
This thirteenth seminar is part 6 of designing an induction motor.The focus is on the stator slot-leakage reactance of equivalent circuits in induction motors. The leakage reactance is the most important concept in the theory of induction motors. It not only determines the maximum torque in the induction motor, but can be said to determine available level of torque at all speeds.In this seminar, leakage reactance is reviewed and described from the perspectives of both the classical theory and the finite element method.
Preliminary Design of a 3-phase Induction Motor (Part 7 : Equivalent circuit reactances — Rotor slot-leakage reactance, differential reactance, and end-winding leakage reactance)
This fourteenth seminar is part 7 and the final lecture on designing an induction motor.This lecture explains the leakage reactance in the equivalent circuit of induction motors. The calculation of the equivalent circuit impedance is completed here and we will use the equivalent circuit to check and evaluate the characteristics and performance of the inductance motor.
IPM Interior Permanent-Magnet Motor (Part 1 : The Rotor)
From this 15th seminar, we will be covering IPM motor design and this will be part 1, the rotor edition.Up until the last seminar, we completed the design of a 10kW induction motor. We will now change only the rotor to IPM. For comparison’s sake, the stator shape of the induction motor will be used as it is for the IPM motor.In this seminar, we will design the V-shaped rotor. I will introduce the historical changes in the rotor of permanent magnet motors and explain what each dimension is heavily dependent on.
IPM Interior Permanent-Magnet Motor (Part 2 : Open-Circuit Calculation)
In this 16th seminar, we will be covering discussion regarding IPM motor open-circuit calculations.We take for consideration an open-circuit where the rotor is inserted into the stator, and where no current is flowing in the stator coils. The ideal magnetic flux density distribution in the air-gap is calculated approximately with the magnetic equivalent circuit method, and FEA is used to check the harmonic component that occurs as a result of the stator slots, etc.Through the changes of the operating point of the magnet on its demagnetization curve, I then explain the effect of the leakage flux that occurs due to the air-gap and the bridges.
IPM Interior Permanent-Magnet Motor (Part 3 : Open-Circuit EMF Ripple and Cogging)
In this 17th seminar, we will be covering discussion regarding the IPM motor open-circuit condition, where I explain the EMF and cogging necessary for evaluation in the open-circuit condition.First, we evaluate the EMF by focusing on the dips in flux-linkage that occurs as a result of the slot-openings, then similarly evaluate the cogging torque that occurs due to the stator slots.
This 18th seminar is part 4 of the IPM motor and will cover the synchronous inductances and the phasor diagram.Synchronous inductances are determined by 3-phase to 2-phase conversion and characteristics such as current dependence of the synchronous inductances are explained. At the end of the seminar, we check the relationship between EMF, voltage drop in the dq-axis, and terminal voltage using phasor diagrams.
Synchronous Reluctance Motor (Synchronous inductance & phasor diagram)
In this 19th seminar, we will be covering the synchronous reluctance motor.As we previously used the stator core of the induction motor, similar to our previous work with the IPM, the seminar this time will explain the features of the synchronous reluctance motor as the induction motor and the IPM are compared each time.Because the rotor of the synchronous reluctance motor is actually rather fragile, this is investigated not only magnetically, but also evaluated in terms of mechanical strength.
Wound-field Synchronous Motor (1. Design and Open-circuit Operation)
In this 20th seminar, we will be covering the wound-field synchronous motor.As we have previously done before, the stator of the induction motor will be used as the stator of the wound field synchronous motor.The rotor of the wound-field synchronous motor has a field winding, not a magnet. The most notable feature is that field current can be changed, but it needs to be appropriately controlled.In this seminar we will design the rotor shape as I explain the feature of the wound-field motor.Next time we will discuss the EMF of the wound-field synchronous motor and its performance.
Wound-field Synchronous Motor (2. Open-circuit Operation)
ABSTRACTIn this 21th seminar, we will continue to study the wound-field synchronous motor.This time we will evaluate the open circuit characteristics of the wound field synchronous motor and focus particularly on the EMF. The EMF is evaluated from various aspects such as static magnetic flux distribution, flux linkage of each phase, search coil results for each teeth, etc.Next time we will discuss the synchronous motion of the wound-field synchronous motor.If you have any comments for Prof. Miller, please.Video run-time: 26:13Video with caption by YouTubeThese automatic captions are generated by machine learning algorithms, so the quality of the captions may vary.(If you do not have access to YouTube, please see the notice at the bottom of…
Wound-field Synchronous Motor (3. Synchronous operation)
In this 22nd seminar, we will continue with the wound-field synchronous motor. This time we will apply currents to the armature and stator and calculate steady-state operation at rated speed and load. We will check the relationship between the armature and stator currents for each current phase and review the magnetic flux lines and magnetic flux density distribution in each current phase.
Wound-field Synchronous Motor (4. Synchronous operation & phasor diagram)
In this 23rd seminar, we will continue to cover discussion regarding the synchronous operation of the wound-field synchronous motor.This time, we will obtain the average torque from the results of static magnetic field analysis, then check the wound-field synchronous motor from various characteristics such as the relationship between the field current and the torque.We encourage viewing this video after having seen video 22, as this video follows that previous video very closely.
In this 24th seminar, we will be covering the Switched Reluctance Motor.Switch reluctance motors have projecting poles on both the stator and rotor, so it is termed “doubly salient”. This time, we will introduce the features of SR motors that carry DC current in one direction instead of AC sine waves.
In this 25th seminar, we will continue to discuss the Switched Reluctance Motor.This lecture will explain the procedure of calculating the average torque of the Switched Reluctance Motor using fundamental electromagnetic theory.It is important to comprehend magnetic saturation since inductance, which plays a significant role in understanding motor characteristics, is dependent on conditions such as magnetic saturation.Magnetic saturation is checked using the magnetic flux density contour and flux line.
In this 26th seminar, we will check the number of slots and poles focusing on the PM brushless motor. The waveforms of motor characteristics such as flux linkage, EMF, current, torque and terminal voltage are strongly influenced by the number of slots and poles as well as the ratio of slot per pole. In this video we will check how the numbers of slots and poles affect the layout of the windings.In the next video we will consider the coil span and look closer at the number of poles.
In this 27th seminar, we will continue our discussion from the previous 26th seminar, and the number of slots and poles will be discussed in this Part II session.I will explain the above topic by focusing on the pitch factor (chording factor) in this lecture.By listening to the previous 26th and the current 27th seminars, you will be able to get a comprehensive idea on calculating and understanding the distribution and pitch (chording) factors.
In this 28th seminar, I will explain the fields and windings.The field theory behind the winding theory, as well as the field calculation that comes after the windings have been designed, will be described in this lecture.For the winding factor, which is an important parameter related to the windings, its definition and the calculation method will also be explained.
Inductance Analysis of Electric Machines by Classical and Numerical Methods
In Video No. 29, we will discuss a very important topic of the inductance of electric machines, which is constantly in the mind of the machine designer and of the control engineers responsible for inverters and motion control.
In this 30th seminar, I would like to define and discuss the concept of magnetizing inductance. It is a term that we often encounter in connection with AC machines, especially in the design of these machines and in the classical theory.
In this 31st seminar, we will explain the torque ripple in the IPM. This time, we will focus on the saliency, which is a very important feature of IPM motors, and pay attention to the role of harmonics in reluctance torque.
In this 33rd seminar, I would like to discuss a rather theoretical idea which I have called “inherent saliency” or “innate saliency.”This saliency is very useful when comparing the difference in rotor geometry and is free from the effects of winding harmonics, slotting, and magnetic saturation.
Inherent saliency of the synchronous reluctance motor
In this 34th seminar,I would like to use the sine-distributed winding to study the inherent saliency of a synchronous reluctance motor.This video is a continuation of videos to 30 to 33, in which we developed the concept of the sine-distributed winding and showed how it can be modelled in JMAG.
Inherent saliency of the wound-field synchronous motor
In this 35th seminar, I would like to complete the series of examples in which we have used the sine-distributed winding to study the inherent saliency of various synchronous motors. The last example is the wound-field synchronous motor.This theory of the ideal model can be found in various conference and papers going back many decades.Nevertheless they explain the underlying concepts in machine design that remain important today.
In this 36th seminar, I would like to discuss the concept of leakage. I will explain the general characteristics of leakage flux in a magnetic device with a simple topology. In the next video, we will turn to a more quantitative approach and consider the topic of leakage inductance.
For the 37th to 40th seminars, I would like to develop the concepts of leakage inductance, mutual inductance, and coupling coefficient.In this Video 37, labeled “Part 2”, we’ll begin by calculating the magnetic field and making a few simple checks.In the next seminar, we will use the same field calculation to extract the values of the self- and mutual inductances and the coupling coefficient k.
Leakage Inductance, Mutual Inductance, Coupling Coefficient and Equivalent Circuits (Part 3 : L M and k)
This 38th seminar is Part 3 of a short series of videos on leakage flux, leakage inductance, coupling coefficient and equivalent circuits.We can check the self-inductance L, mutual inductance M, and the coupling coefficient k.Additional post-processing functions for calculating engineering parameters like inductance are not used. Here we will use the most simplest definition, the flux-linkage per ampere.
This 39th seminar is Part 4 of a short series of videos on leakage flux, leakage inductance, coupling coefficient, and equivalent circuits.In the previous video, we ended up with an ideal T equivalent circuit for the example 2-winding transformer.In this video, we will generalise the equivalent circuit rigorously and examine some important variants that arise from the apportionment of leakage inductance between the primary and secondary.
This 40th seminar is Part 5—the last part—of a short series of videos on leakage flux, leakage inductance, coupling coefficient, and equivalent circuits.What we will see in this video—even for a relatively simple physical device—is that the classical equivalent-circuit model has some notable weaknesses in the presence of magnetic saturation.We will see how the finite-element method can be used to expose and also resolve the uncertainties inherent in the classical equivalent-circuit model.
In this 41st seminar, I would like to discuss the interpretation of certain boundary conditions, the ones that were the subject of Engineer’s Diary No. 61.Here I will use a cable duct to explain the interpretation of boundary conditions.There are many instances where understanding boundary conditions can help in the interpretation of physical phenomena and the choice of suitable boundary conditions in analysis and simulation.
In the last two seminars, we considered a magnetostatic solution with DC excitation in the two busbars, but in this seminar, we will extend the study to AC conditions with AC excitation.We will proceed to evaluate the differences in magnetic flux density and current density due to differences in duct material and frequency.
In the last two seminars, we considered a magnetostatic solution with DC excitation in the two busbars, but in this seminar, we will extend the study to AC conditions with AC excitation.We will proceed to evaluate the differences in magnetic flux density and current density due to differences in duct material and frequency.
In this 44th seminar, we will extend our study of eddy-currents in the walls of a cable duct, which we began in the previous seminar.The aim is to examine the effects of frequency and geometry on the behaviour of the eddy-currents.We also quote the contents of Engineer's Diary No. 64, so be sure to check out Engineer's Diary as well.
Inductance : Fundamental theory and practical aspects in analysis
In this 45th seminar we will explain inductance. Inductance is a “terminal” quantity that can only be measured at the terminals of a circuit, much like resistance, capacitance, EMF, etc. Here we will explain inductance in terms of both its theoretical and practical aspects.
This 46th seminar shows a graphical representation of harmonic interactions described by the classical mathematics of Fourier series.We display some of the ideas in the harmonic analysis of the waveforms of flux and ampere-conductors in AC machines such as the brushless PM AC motor.Many of these also apply to induction motors, so we will also introduce them during asynchronous operation.
As in the 46th seminar, the 47th seminar examines the graphical representation of harmonic interactions described by Fourier series. We will represent the basic phenomena of rotating magnetic fields graphically and confirm the mechanisms that produce the torque as well as visualize the harmonic components. The next seminar will look at time harmonics in the current waveform and unbalanced operation.
The 48th seminar looks at the time harmonics in the current waveform and unbalanced operation. The final demonstration examines the space harmonics, with no time harmonics in the phase current waveforms.These three seminars illustrate the necessity of analyzing higher harmonic components of the Fourier series to understand what is going on in the complex process of torque production in AC machines.
This video uses JMAG to look at air-gap sheer stress and torque.We can model the physical reality in JMAG to visualize the interactions between the stator and rotor.In this way, JMAG finite element analysis complements classical theory to give us a deeper understanding of motor behavior.
The 50th seminar entitled Per-unit Systems explains ways to express numerical values in complex systems and the practical day-to-day rules used in power system analysis.
The ‘what-if’ questions of butt-joints and other gaps in electric machines
There are several types of gaps and joints in any electric machine.The 52nd seminar takes a look at air gaps as well as some other typical gaps and joints.In this video, we will also consider how to include features that may be too small or too uncertain to make a reasonable mesh in a finite-element calculation.
Uncertainties in design calculations for electric machines
This video delves into the uncertainties associated with design calculations of electric machines.There is no way to rid ourselves of these uncertainties, even in simulations that use a large amount of data.We will look at and breakdown a variety of these problems.
This video provides as a short introduction on flux linkage. Professor Miller has created an illustration of an oil field on the first slide to make flux linkage easy to imagine for everyone new to the subject.A flux flood is like oil gushing from a well, but flux linkage is like oil captured at the well-head. Let's learn a little bit about the flux linkage that control engineers who want to control torque and speed must consider.
Video 54 compared linkage flux at terminals with oil captured at the well-head in an oil field . This series will explain the systematic process to obtain important results from a finite element analysis of a brushless PM motor.
The 56th seminar builds on videos 54 and 55 to unravel the mystery of torque and inductance. We will examine instantaneous torque and changes in inductance as well as the effects of rotor saliency. Insight into these basic concepts gives us a more in-depth understanding of motor performance and a potentially nasty surprise.
The 57th seminar continues our series that began in video 54 by examining harmonics analysis and skew. We will look at voltage waveforms, harmonic components, the effects of skew, dq-axis transformation, and how each interacts with the other. Skew alone cannot completely mitigate the winding harmonics. Let’s consider what can be done together through this video.
The 58th seminar is another in the series that began in video 54. We are now ready to glean insight from the visualization of the phase EMF about the shape of the energy conversion loop, the power factor, and the interactions of harmonics. This also includes a phasor diagram that illustrates the behavior of synchronous machines. We will record the flux density in four main locations of the motor as well to understand changes with and without load. This seminar takes advantage of Excel, a specially written FORTRAN program and other tools to unravel the complexity of electric machines.
The 59th seminar describes how the combination of slots, poles and phases affect the torque, efficiency, speed and other motor characteristics. This video is packed with information helpful for students and engineers who want to understand basic motor design.
IPM inductance measurements taken in my own home workshop!?This 60th seminar describes a unique approach for engineers to measure the phase and synchronous inductance, even where resources and facilities are limited.
The 61st seminar uses a flux meter to explore the ferrite magnets of a DC motor and the innerworkings of an innovative IPM motor. We examine several tests at the core of motor design from the inductance measurements with current in the windings to the behavior of flux seen in the shadow winding but not main winding.
The 62nd seminar describes the true nature of the flux waves essential to electric machine design. We will unveil the secrets to the 3rd harmonic and examine various possibilities, such as the potential of 5-phase/7-phase multi-phase machines. This video interweaves theory with practical examples of design concepts that capitalize on the space-harmonics that are of particular interest in special applications and high-performance drives.
The 63rd seminar delves deeper into the profound world of flux waves introduced in the pervious video. We will look not only at the theory behind various winding configurations and the related harmonics but also practical examples from single-phase and multi-phase to dual three-phase and five-phase arrangements. The slightly unconventional design concepts touched on in this video are essential viewing for every engineer.
The 64th seminar will continue to explore deeper into the profound world of flux waves. We will take a step outside of conventional design to not only look at principles for enhancing torque in dual 3-phase and 5-phase configurations but also injecting harmonic currents to strengthen the magnetic flux. This video provides fantastic insight into the potential of multi-phase motors from both theoretical and practical standpoints. This seminar is not to be missed.
Steady-state short-circuit operation of a PM brushless machine – I
As the start of a new series, the 65th seminar examines the steady-state short-circuit operation of a brushless permanent-magnet machine, which is one of the most important test conditions. Often thought of as a special or dangerous test, the short-circuit operation is knowledge critical for designers. This series not only touches on the depth of this design concept but is also packed with expertise helpful on the development floor. These seminars take a step away from convention to provide insight essential for engineers.
Steady-state short-circuit operation of a PM brushless machine – II
The 66th seminar digs even deeper into the steady-state short-circuit operation of a PM brushless machine. We examine the operating points and leakage paths of magnets as well as practical examples that illustrate design considerations necessary for short-circuit currents. This seminar brings together first-hand expertise and innovative approaches to finite element analysis essential to every engineer involved with design and development.
The 67th seminar explores the electrical characteristics of permanent magnet (PM) AC generators to examine the relationship between torque, speed, terminal voltage and current under a resistive load. This video also looks at the internal resistance and short-circuit current unique to small generators as well as investigates the effects adding an external resistance has on the characteristics. This seminar that brings together points beneficial to real-world design in the most accessible manner is not to be missed.
Inherent characteristics of a PM AC generator – II
The 68th seminar explores electrical characteristics when the permanent magnet (PM) AC generator has a rectifier (DC chopper) as a simple load. This video examines how the changes seen in the load resistance of the chopper control affects the current, torque, and output in detail while looking at practical simulation examples. This seminar also introduces ways to prevent overheating and other key safety measures using the duty-cycle of a PWM and current control. These insights are essential viewing for engineers interested in the application design of PM generators and power converters.
Inherent characteristics of wound-field synchronous machines – I
The 69th seminar takes a methodical look at the operating characteristics fundamental to wound-field synchronous machines (WFSM). This video provides accessible explanations about the various relationships between the generated EMF, terminal voltage, armature current, and synchronous reactance while focusing primarily on open-circuit and short-circuit characteristics. We also touch broadly on grid codes, safely operating machines during failures, and other trends related to the latest technologies from design and operation standpoints. The information in this seminar is invaluable to engineers in a wide range of fields, whether EV drives or power conversion control and electric power systems.
The 71st seminar reviews and systematically organizes the basics of equivalent circuits and phasor diagrams for synchronous machines and examines the relationship with finite element analysis (FEM). The video also touches on the difference between calculating the characteristics directly and calculating the characteristics through post-processing using FEM to clarify when to take advantage of equivalent circuit parameters in designs and evaluations. This seminar provides information essential for designers struggling to understand FEM results and anyone else who might want to review synchronous machine analysis.
The 72nd seminar takes a deeper look at the operating characteristics of synchronous machines, systematically explaining the output-load angle characteristics, V-curves, and MVA charts (power capability curves) that define the operating limits. Drawing on classical phasor‑diagram‑based analysis, the video also discusses the use of the finite element method (FEM) to account for nonlinear magnetic saturation. It further covers a range of theories indispensable for practical operation, including the effects of saliency, steady-state stability concepts, transmission characteristics, and the Ferranti effect.By bridging theory and real-world practice, this seminar provides essential foundations for designers and analysts seeking a clear understa…
The 73rd seminar serves as the final session of the five-seminar series on synchronous machine analysis (Vol. 69–73). Focusing on “inverter-fed machines,” which are indispensable in modern design practice, it outlines a practical approach to analysis aligned with real-world operation, moving beyond classical analysis based on commercial power-driven systems. The seminar covers topics such as changes in the voltage waveform due to PWM control and the concept of space vectors.In particular, it is crucial to examine how magnetic saturation and mutual saturation affect various parameters by combining finite element analysis (FEM) with phasor diagrams in order to ensure consistency with actual device behavior. This process offers perspectives d…
