Torsional Vibration Analysis of an Electric-Drive Powertrain Via System Simulations with Simcenter Amesim and JMAG-RT

Florent Pasteur / Damien Aguilera
Simulation & Test Solutions, Siemens Digital Industry Software
Gabriel Autefage
Simulation & Test Solutions, Simcenter Amesim, Electro-mechanical, Siemens Digital Industry Software

Abstract

Modeling and simulation of Torsional Vibration Analysis of electric drive is largely done using a suit of 3D simulation tools. However, for some aspects, system simulation can support and provide answers quickly and efficiently. In this talk we will present the 1D Simcenter Amesim, a multi-physic simulation tool, in combination with JMAG-RT to address relevant use case of the TVA of an electric drive.
