POWERSYS is pleased to invite you to a course especially prepared by Professor Tim Miller.
開催趣旨 ｜ 開催概要 ｜ プログラム ｜ お申込み ｜The Green Book ｜ お問い合わせ
開催趣旨
Professor Tim Miller has 45 years’ experience in the electrical engineering industry and as manager and leader of research laboratories at the University of Glasgow and at General Electric (USA), where he was a member of the team that developed the original “IPM”.
- This course provides the theoretical and practical basis for designing brushless permanent-magnet machines,
- The course is illustrated with detailed examples of precise calculations using JMAG software,
- The design theory and the finite-element method is used to maximize the efficiency and productivity of these calculations.
T.J.E. Miller
開催概要
| 主催 | POWERSYS |
| 日程 | 2015年4月7日（火）～ 2015年4月9日（木） 9：00～17：00（3日目のみ16：00終了） |
| 会場 | Steigenberger Airport Hotel Frankfurt（ドイツ：フランクフルト） http://en.steigenberger.com/Frankfurt/Steigenberger-Airport-Hotel |
| 受講日数 | 3日間 |
| 定員 | 20名 |
| 参加費 | 企業：2000ユーロ （VAT別） 学生：1300ユーロ （VAT別） |
| URL | http://www.powersys-solutions.com/event/design-of-brushless-permanent-magnet-machines-training-course/ |
プログラム
- No. of slots, poles and phases
- Geometry
- Configuration: Interior/Exterior; Saliency (Surface-magnet/IPM)
- Stator design: Shape; Slots/pole; Slot design
- Open-circuit
- Magnet flux distribution by FEA.Basic levels of Flux and Flux-density
- Flux-linkage of stator winding as the rotor rotates. Open-circuit EMF
- Cogging torque
- Windings
- Magnet flux distribution by FEA.Basic levels of Flux and Flux-density
- Torque – how it is produced
- Distinction between average torque and instantaneous torque
- Effective use of FEA
- Drive and control
- Squarewave and sinewave drive
- Control modes: voltage, current, torque, speed, position
- Machine model for drive system simulation
- Effects of saturation
- Cooling
- Demagnetization
※プログラム内容は、都合により変更となる場合がございます。
お申込み
POWERSYSのWEBサイトよりお申込みください。
The Green Book
The Green Book : “Design of Brushless Permanent-Magnet Machines”
著者: J.R. Hendershot & T.J.E. Miller.
This 822-page brushless machine design book is generously illustrated in color as the authors have tried to catch up with the progress over the last 16 years of PM bushless machine design and development since their well-known 1994 book. Almost the entire work is the direct result of intensive consulting by the authors, in collaborating with many of the leading producers of brushless permanent-magnet machine products worldwide. The book was written with a focus on actual engineering practice and tries to deal with most of the questions that arise on a daily basis in PM brushless machine design. The authors’ partnership is a long-standing combination of theoretical, practical and consulting experience, while the book with its rich illustrations of industrial products celebrates the rich engineering accomplishments of design engineers from all over the world.
This 822-page brushless machine design book is generously illustrated in color as the authors have tried to catch up with the progress over the last 16 years of PM bushless machine design and development since their well-known 1994 book. Almost the entire work is the direct result of intensive consulting by the authors, in collaborating with many of the leading producers of brushless permanent-magnet machine products worldwide. The book was written with a focus on actual engineering practice and tries to deal with most of the questions that arise on a daily basis in PM brushless machine design. The authors’ partnership is a long-standing combination of theoretical, practical and consulting experience, while the book with its rich illustrations of industrial products celebrates the rich engineering accomplishments of design engineers from all over the world.
