Introducing New Functions of JMAG-Designer Ver.17.1

A video complete with voice audio has been prepared to offer our users a better understanding of the new functions in JMAG-Designer Ver.17.1.
This will also include demonstrations using JMAG-Designer Ver.17.1 itself.
Demonstration data can be downloaded from JMAG function tutorials.
We encourage all of our users to take a look for themselves to experience these offers firsthand.

*This is a lecture that can be attended via internet in your own time and for as many times as required.

View

 Remember me
Sign In
Forgot password?
Create an account (Free) About authentication ID for JMAG website
In order to view the download data or video, you need the ID and password.
About authentication ID for JMAG website
  • JMAG Software Authorized User ID
    This ID is issued based on the JMAG license agreement. At the time of contract, we will guide you to the license administrator by e-mail.
    It is also available for those who are in the free trial period.
    *A user ID and password which is described in the e-mail we sent you with JMAG license file are required.
  • JMAG WEB MEMBER (Free membership)
    If you have not registered yet, please apply below.
    JMAG WEB MEMBER (Free membership) > Create an Account

What is JMAG-Designer Ver.17.1 ?

  • FEM Engines
    – Large-scale models with tens of millions of elements can be analyzed.
    – Two-dimensional analysis can be solved much faster.
  • Modelling
    – JMAG stand-alone has capabilities, such as linking with a control circuit, widely expanding the breadth of multiphysics.
  • Design Support Functions
    – Optimization function and JMAG-RT system were optimized so that it can be comfortably used even among trial and error design work flow.
  • Frameworks
    – The flexibility of constructing a distributed processing system has greatly improved and it has become possible to use on various environments.
    – A new geometry template has been added, making model reuse easier.
  • Documents
    Information has been substantially added and updated.
    – JMAG-RT Model Library Update
    – New Function Tutorials
    – New Application Catalogues

Other additions and improvements beside these have also been added.
– Introducing JMAG-Designer Ver.17.1
– Module download (  user verification required )
