Introducing New Functions of JMAG-Designer Ver.18.0

A video complete with voice audio has been prepared to offer our users a better understanding of the new functions in JMAG-Designer Ver.18.0.
This will also include demonstrations using JMAG-Designer Ver.18.0 itself.
Demonstration data can be downloaded from JMAG function tutorials.
We encourage all of our users to take a look for themselves to experience these offers firsthand.

*This is a lecture that can be attended via internet in your own time and for as many times as required.

View

 Remember me
Sign In
Forgot password?
Create an account (Free) About authentication ID for JMAG website
In order to view the download data or video, you need the ID and password.
About authentication ID for JMAG website
  • JMAG Software Authorized User ID
    This ID is issued based on the JMAG license agreement. At the time of contract, we will guide you to the license administrator by e-mail.
    It is also available for those who are in the free trial period.
    *A user ID and password which is described in the e-mail we sent you with JMAG license file are required.
  • JMAG WEB MEMBER (Free membership)
    If you have not registered yet, please apply below.
    JMAG WEB MEMBER (Free membership) > Create an Account

What is JMAG-Designer Ver.18.0 ?

  • Winding editor
    Fast and easy creation of your winding without the need to create every single winding. Visualize and modify with simplicity the winding pattern. Parametrize the winding to compare selected winding
  • Efficiency Map
    Create accurate efficiency map quickly and easily in JMAG-Designer model with a breakdown of the losses each selected operating point. Allowing for parametric studies based on efficiency maps in the early stage of the development. Furthermore, a high precision map can be generated using JMAG control circuits using PWM drive as well as Iron loss studies.
  • Control in JMAG-Designer
    Get the impact of your control drive on the losses and vibration of your FEA model. Get access to new components and the possibility to create your own.Integrate JMAG-RT model in co-simulation in order to speed-up you calculations using control circuit.
  • Topology optimisation
    Explore new design concepts without the need of CAD parameters. Perfect for early design phase as the potential resulting shapes are only limited by the selected design space.

Other additions and improvements beside these have also been added.
