[RTML-009] PMSM/SPM Constant rating 1(kW) 3-phase

Sign in to download the data
Remember me
Sign In
Create an account (Free) About authentication ID for JMAG website

Available in MATLAB version R2021a and later.

Features and principal use

Slim type, Power source for compact air conditioner compressors etc.

Geometry display on JMAG-Express

Geometry display on JMAG-Express

Type

Model 1k_D_D_S
Model name PMSM
Max. Power 1(kW)
Voltage/Current DC100(V)/20(A)
Number of Poles 6
Number of Slots 18
Number of Phases 3
Rotor SPM
Stator (Outside Diameter) 115(mm)
Stator (Inside Diameter) 59(mm)
Stator Distributed winding
Number of Turns 33
Height 14(mm)
Magnet Neodymium sintered
Inertia Moment 1.13e-4(kg·m^2)
Mass 1.82(kg)
Max. Current 28.3(Apeak)

Calculation results of JMAG-Designer

Average torque(N·m) 3.6(N·m)
Ld 0.29(mH)
Lq 0.42(mH)
Inductance 0.28(mH)
Torque constant 0.128(N·m/A)

Result display on JMAG-RT Viewer Type3

Result display on JMAG-RT Viewer Type3

Calculation condition of efficiency map using JMAG-RT Viewer

– Motor Control

Max.Speed 6000(r/min)
Control Type Max. Power

– Inverter

Max.Voltage 100(V)
Max.Current 28.3(Apeak)
Efficiency Operating range
not less than 90% 76.6(%)
not less than 80% 89.2(%)
not less than 70% 93.0(%)
not less than 60% 94.9(%)
not less than 50% 96.0(%)

* Iron Loss is accounted.
